* Available applications in GCC may vary by motherboard model. Support for GIGABYTE Control Center (GCC) * Whether the fan speed control function is supported will depend on the fan you install. RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devicesġ x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB headerĥ x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header)Ĩ x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)ġ x USB Type-C® header, with USB 3.2 Gen 2 supportġ x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.ġ x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIEX4)ġ x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)ġ x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB) (Actual data rate may vary depending on environment and equipment.)ġ x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16) Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) To configure 7.1-channel audio, access the audio software for audio settings. * You can change the functionality of an audio jack using the audio software. (Graphics specifications may vary depending on CPU support.) * Support for HDMI 2.0 version and HDCP 2.3. * Support for DisplayPort 1.2 version and HDCP 2.3ġ x HDMI port, supporting a maximum resolution of Hz
Integrated Graphics Processor-Intel® HD Graphics support:ġ x DisplayPort, supporting a maximum resolution of Hz Support for Extreme Memory Profile (XMP) memory modules Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) LGA1700 socket: Support for the 13th and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors
